Adding an image upload field to categories and taxonomies

This is an updated version of the original post. It started out as a tutorial demonstrating how to add an image to a category but I’ve since amended it to include adding an image to a custom taxonomy as well.

Looking for how to upload an image to a WooCommerce product page?

How to add an image field to the category field

Here’s what we’re aiming to achieve for standard categories. Details on doing the same for custom taxonomies are below.

There are a lot of tutorials around for how to add fields to categories. However, these mostly use an old method where data is saved to the theme options. But since WordPress 4.4, it’s been possible to save meta data for taxonomies in a similar way to saving post data. Secondly, I wanted the ability to upload an image for the category using the default WordPress media manager. So I came up with the following class:

The whole thing

/**
 * Plugin class
 **/
if ( ! class_exists( 'CT_TAX_META' ) ) {

class CT_TAX_META {

  public function __construct() {
    //
  }

 /*
  * Initialize the class and start calling our hooks and filters
  * @since 1.0.0
 */
 public function init() {
   add_action( 'category_add_form_fields', array ( $this, 'add_category_image' ), 10, 2 );
   add_action( 'created_category', array ( $this, 'save_category_image' ), 10, 2 );
   add_action( 'category_edit_form_fields', array ( $this, 'update_category_image' ), 10, 2 );
   add_action( 'edited_category', array ( $this, 'updated_category_image' ), 10, 2 );
   add_action( 'admin_enqueue_scripts', array( $this, 'load_media' ) );
   add_action( 'admin_footer', array ( $this, 'add_script' ) );
 }

public function load_media() {
 wp_enqueue_media();
}

 /*
  * Add a form field in the new category page
  * @since 1.0.0
 */
 public function add_category_image ( $taxonomy ) { ?>
   <div class="form-field term-group">
     <label for="category-image-id"><?php _e('Image', 'hero-theme'); ?></label>
     <input type="hidden" id="category-image-id" name="category-image-id" class="custom_media_url" value="">
     <div id="category-image-wrapper"></div>
     <p>
       <input type="button" class="button button-secondary ct_tax_media_button" id="ct_tax_media_button" name="ct_tax_media_button" value="<?php _e( 'Add Image', 'hero-theme' ); ?>" />
       <input type="button" class="button button-secondary ct_tax_media_remove" id="ct_tax_media_remove" name="ct_tax_media_remove" value="<?php _e( 'Remove Image', 'hero-theme' ); ?>" />
    </p>
   </div>
 <?php
 }

 /*
  * Save the form field
  * @since 1.0.0
 */
 public function save_category_image ( $term_id, $tt_id ) {
   if( isset( $_POST['category-image-id'] ) && '' !== $_POST['category-image-id'] ){
     $image = $_POST['category-image-id'];
     add_term_meta( $term_id, 'category-image-id', $image, true );
   }
 }

 /*
  * Edit the form field
  * @since 1.0.0
 */
 public function update_category_image ( $term, $taxonomy ) { ?>
   <tr class="form-field term-group-wrap">
     <th scope="row">
       <label for="category-image-id"><?php _e( 'Image', 'hero-theme' ); ?></label>
     </th>
     <td>
       <?php $image_id = get_term_meta ( $term -> term_id, 'category-image-id', true ); ?>
       <input type="hidden" id="category-image-id" name="category-image-id" value="<?php echo $image_id; ?>">
       <div id="category-image-wrapper">
         <?php if ( $image_id ) { ?>
           <?php echo wp_get_attachment_image ( $image_id, 'thumbnail' ); ?>
         <?php } ?>
       </div>
       <p>
         <input type="button" class="button button-secondary ct_tax_media_button" id="ct_tax_media_button" name="ct_tax_media_button" value="<?php _e( 'Add Image', 'hero-theme' ); ?>" />
         <input type="button" class="button button-secondary ct_tax_media_remove" id="ct_tax_media_remove" name="ct_tax_media_remove" value="<?php _e( 'Remove Image', 'hero-theme' ); ?>" />
       </p>
     </td>
   </tr>
 <?php
 }

/*
 * Update the form field value
 * @since 1.0.0
 */
 public function updated_category_image ( $term_id, $tt_id ) {
   if( isset( $_POST['category-image-id'] ) && '' !== $_POST['category-image-id'] ){
     $image = $_POST['category-image-id'];
     update_term_meta ( $term_id, 'category-image-id', $image );
   } else {
     update_term_meta ( $term_id, 'category-image-id', '' );
   }
 }

/*
 * Add script
 * @since 1.0.0
 */
 public function add_script() { ?>
   <script>
     jQuery(document).ready( function($) {
       function ct_media_upload(button_class) {
         var _custom_media = true,
         _orig_send_attachment = wp.media.editor.send.attachment;
         $('body').on('click', button_class, function(e) {
           var button_id = '#'+$(this).attr('id');
           var send_attachment_bkp = wp.media.editor.send.attachment;
           var button = $(button_id);
           _custom_media = true;
           wp.media.editor.send.attachment = function(props, attachment){
             if ( _custom_media ) {
               $('#category-image-id').val(attachment.id);
               $('#category-image-wrapper').html('<img class="custom_media_image" src="" style="margin:0;padding:0;max-height:100px;float:none;" />');
               $('#category-image-wrapper .custom_media_image').attr('src',attachment.url).css('display','block');
             } else {
               return _orig_send_attachment.apply( button_id, [props, attachment] );
             }
            }
         wp.media.editor.open(button);
         return false;
       });
     }
     ct_media_upload('.ct_tax_media_button.button');
     $('body').on('click','.ct_tax_media_remove',function(){
       $('#category-image-id').val('');
       $('#category-image-wrapper').html('<img class="custom_media_image" src="" style="margin:0;padding:0;max-height:100px;float:none;" />');
     });
     // Thanks: https://stackoverflow.com/questions/15281995/wordpress-create-category-ajax-response
     $(document).ajaxComplete(function(event, xhr, settings) {
       var queryStringArr = settings.data.split('&');
       if( $.inArray('action=add-tag', queryStringArr) !== -1 ){
         var xml = xhr.responseXML;
         $response = $(xml).find('term_id').text();
         if($response!=""){
           // Clear the thumb image
           $('#category-image-wrapper').html('');
         }
       }
     });
   });
 </script>
 <?php }

  }

$CT_TAX_META = new CT_TAX_META();
$CT_TAX_META -> init();

}

Breaking it down

We can go through this step by step. We’ve created a class to hold the code to make it easier to re-use but you can easily use this code in your functions.php file if you prefer. You’d just need to refactor it slightly.

Add new meta data term

Our first function adds a new field to the Add New Category form.

Note that we’re storing the attachment ID for the image in a hidden input field then displaying the thumbnail to the user. We’re also adding two buttons, the JavaScript for which we’ll add later.

public function add_category_image ( $taxonomy ) { ?>
   <div class="form-field term-group">
     <label for="category-image-id"><?php _e('Image', 'hero-theme'); ?></label>
     <input type="hidden" id="category-image-id" name="category-image-id" class="custom_media_url" value="">
     <div id="category-image-wrapper"></div>
     <p>
       <input type="button" class="button button-secondary ct_tax_media_button" id="ct_tax_media_button" name="ct_tax_media_button" value="<?php _e( 'Add Image', 'hero-theme' ); ?>" />
       <input type="button" class="button button-secondary ct_tax_media_remove" id="ct_tax_media_remove" name="ct_tax_media_remove" value="<?php _e( 'Remove Image', 'hero-theme' ); ?>" />
    </p>
   </div>
 <?php
 }

We add this via a hook which we call in our init function:

add_action( 'category_add_form_fields', array ( $this, 'add_category_image' ), 10, 2 );

If you wanted to add this field to a different taxonomy, e.g. for a custom post type, you’d need to replace the reference to category with a reference to your own taxonomy slug. For example, if you add created a genre taxonomy you would hook this function via add_action( 'taxonomy_add_form_fields', array ( $this, 'add_category_image' ), 10, 2 ).

If you’ve just added this and nothing else, you’ll see the buttons appear in your form but they won’t yet work. To get them to function as we need, we add some inline JavaScript to the footer via the admin_footer hook:

add_action( 'admin_footer', array ( $this, 'add_script' ) );

Then the function add_script:

/*
 * Add script
 * @since 1.0.0
 */
 public function add_script() { ?>
   <script>
     jQuery(document).ready( function($) {
       function ct_media_upload(button_class) {
         var _custom_media = true,
         _orig_send_attachment = wp.media.editor.send.attachment;
         $('body').on('click', button_class, function(e) {
           var button_id = '#'+$(this).attr('id');
           var send_attachment_bkp = wp.media.editor.send.attachment;
           var button = $(button_id);
           _custom_media = true;
           wp.media.editor.send.attachment = function(props, attachment){
             if ( _custom_media ) {
               $('#category-image-id').val(attachment.id);
               $('#category-image-wrapper').html('<img class="custom_media_image" src="" style="margin:0;padding:0;max-height:100px;float:none;" />');
               $('#category-image-wrapper .custom_media_image').attr('src',attachment.url).css('display','block');
             } else {
               return _orig_send_attachment.apply( button_id, [props, attachment] );
             }
            }
         wp.media.editor.open(button);
         return false;
       });
     }
     ct_media_upload('.ct_tax_media_button.button');
     $('body').on('click','.ct_tax_media_remove',function(){
       $('#category-image-id').val('');
       $('#category-image-wrapper').html('<img class="custom_media_image" src="" style="margin:0;padding:0;max-height:100px;float:none;" />');
     });
     // Thanks: https://stackoverflow.com/questions/15281995/wordpress-create-category-ajax-response
     $(document).ajaxComplete(function(event, xhr, settings) {
       var queryStringArr = settings.data.split('&');
       if( $.inArray('action=add-tag', queryStringArr) !== -1 ){
         var xml = xhr.responseXML;
         $response = $(xml).find('term_id').text();
         if($response!=""){
           // Clear the thumb image
           $('#category-image-wrapper').html('');
         }
       }
     });
   });
 </script>
 <?php }

Now, when clicking the Add Image button the WordPress media uploader will launch and allow you to select an image. It’ll grab the ID of the selected image and insert that into the hidden field with the ID category-image-id. This is the field that we’ll actually save. In order to present the image to the user, we use some jQuery to populate the div with the ID category-image-wrapper with the thumbnail image. This isn’t strictly necessary but just makes for a better user experience.

Likewise, if the user clicks the Remove Button image, the hidden field will be cleared and the image removed.

Save the meta data

Next, we need to be able to save our image meta field when the user clicks Add New Category. To do this, we hook into the created_category hook. If you’re working with a different taxonomy, then you’ll need to work with the created_{$taxonomy} hook where {$taxonomy} is your custom taxonomy slug. So our hook is:

add_action( 'created_category', array ( $this, 'save_category_image' ), 10, 2 );

And our function is:

public function save_category_image ( $term_id, $tt_id ) {
   if( isset( $_POST['category-image-id'] ) && '' !== $_POST['category-image-id'] ){
     $image = $_POST['category-image-id'];
     add_term_meta( $term_id, 'category-image-id', $image, true );
   }
 }

This works exactly the same way as add_post_meta by saving the value of our category-image-id field (which contains the attachment ID) to the category ID.

Update the meta data

Now that you’ve save a category with its associated image, you might wish to change the image.

First, we’ll need to add the same fields to the Edit Category form that we added to the Add New Category form. The hook we use is category_edit_form_fields – replace category with your taxonomy slug if needed.

add_action( 'category_edit_form_fields', array ( $this, 'update_category_image' ), 10, 2 );

The function adds our fields to the Edit Category form:

/*
  * Edit the form field
  * @since 1.0.0
 */
 public function update_category_image ( $term, $taxonomy ) { ?>
   <tr class="form-field term-group-wrap">
     <th scope="row">
       <label for="category-image-id"><?php _e( 'Image', 'hero-theme' ); ?></label>
     </th>
     <td>
       <?php $image_id = get_term_meta ( $term -> term_id, 'category-image-id', true ); ?>
       <input type="hidden" id="category-image-id" name="category-image-id" value="<?php echo $image_id; ?>">
       <div id="category-image-wrapper">
         <?php if ( $image_id ) { ?>
           <?php echo wp_get_attachment_image ( $image_id, 'thumbnail' ); ?>
         <?php } ?>
       </div>
       <p>
         <input type="button" class="button button-secondary ct_tax_media_button" id="ct_tax_media_button" name="ct_tax_media_button" value="<?php _e( 'Add Image', 'hero-theme' ); ?>" />
         <input type="button" class="button button-secondary ct_tax_media_remove" id="ct_tax_media_remove" name="ct_tax_media_remove" value="<?php _e( 'Remove Image', 'hero-theme' ); ?>" />
       </p>
     </td>
   </tr>
 <?php
 }

This will also use the JavaScript we added previously to allow us to upload or remove images.

To save the updated field, we hook into edited_category and use update_term_meta. As before, you can use edited_{$taxonomy} for your own taxonomy.

/*
 * Update the form field value
 * @since 1.0.0
 */
 public function updated_category_image ( $term_id, $tt_id ) {
   if( isset( $_POST['category-image-id'] ) && '' !== $_POST['category-image-id'] ){
     $image = $_POST['category-image-id'];
     update_term_meta ( $term_id, 'category-image-id', $image );
   } else {
     update_term_meta ( $term_id, 'category-image-id', '' );
   }
 }

Display the image on the front end

Now all we need is to display the image in our theme. Just use get_term_meta as you would get_post_meta for post data, e.g.:

// Get the current category ID, e.g. if we're on a category archive page
$category = get_category( get_query_var( 'cat' ) );
 $cat_id = $category->cat_ID;
// Get the image ID for the category
$image_id = get_term_meta ( $cat_id, 'category-image-id', true );
// Echo the image
echo wp_get_attachment_image ( $image_id, 'large' );

Adding an image upload to a custom taxonomy

The principle for this is identical to the process above. However, in this example we’re looking at adding the image to a custom taxonomy, specifically the Easy Digital Downloads Download Category. But you should be able to adjust this for any custom taxonomy.

Again, here’s the whole class.

if( ! class_exists( 'Showcase_Taxonomy_Images' ) ) {
  class Showcase_Taxonomy_Images {

    public function __construct() {
     //
    }

    /**
     * Initialize the class and start calling our hooks and filters
     */
     public function init() {
     // Image actions
     add_action( 'download_category_add_form_fields', array( $this, 'add_category_image' ), 10, 2 );
     add_action( 'created_download_category', array( $this, 'save_category_image' ), 10, 2 );
     add_action( 'download_category_edit_form_fields', array( $this, 'update_category_image' ), 10, 2 );
     add_action( 'edited_download_category', array( $this, 'updated_category_image' ), 10, 2 );
     add_action( 'admin_enqueue_scripts', array( $this, 'load_media' ) );
     add_action( 'admin_footer', array( $this, 'add_script' ) );
   }

   public function load_media() {
     if( ! isset( $_GET['taxonomy'] ) || $_GET['taxonomy'] != 'download_category' ) {
       return;
     }
     wp_enqueue_media();
   }

   /**
    * Add a form field in the new category page
    * @since 1.0.0
    */

   public function add_category_image( $taxonomy ) { ?>
     <div class="form-field term-group">
       <label for="showcase-taxonomy-image-id"><?php _e( 'Image', 'showcase' ); ?></label>
       <input type="hidden" id="showcase-taxonomy-image-id" name="showcase-taxonomy-image-id" class="custom_media_url" value="">
       <div id="category-image-wrapper"></div>
       <p>
         <input type="button" class="button button-secondary showcase_tax_media_button" id="showcase_tax_media_button" name="showcase_tax_media_button" value="<?php _e( 'Add Image', 'showcase' ); ?>" />
         <input type="button" class="button button-secondary showcase_tax_media_remove" id="showcase_tax_media_remove" name="showcase_tax_media_remove" value="<?php _e( 'Remove Image', 'showcase' ); ?>" />
       </p>
     </div>
   <?php }

   /**
    * Save the form field
    * @since 1.0.0
    */
   public function save_category_image( $term_id, $tt_id ) {
     if( isset( $_POST['showcase-taxonomy-image-id'] ) && '' !== $_POST['showcase-taxonomy-image-id'] ){
       add_term_meta( $term_id, 'showcase-taxonomy-image-id', absint( $_POST['showcase-taxonomy-image-id'] ), true );
     }
    }

    /**
     * Edit the form field
     * @since 1.0.0
     */
    public function update_category_image( $term, $taxonomy ) { ?>
      <tr class="form-field term-group-wrap">
        <th scope="row">
          <label for="showcase-taxonomy-image-id"><?php _e( 'Image', 'showcase' ); ?></label>
        </th>
        <td>
          <?php $image_id = get_term_meta( $term->term_id, 'showcase-taxonomy-image-id', true ); ?>
          <input type="hidden" id="showcase-taxonomy-image-id" name="showcase-taxonomy-image-id" value="<?php echo esc_attr( $image_id ); ?>">
          <div id="category-image-wrapper">
            <?php if( $image_id ) { ?>
              <?php echo wp_get_attachment_image( $image_id, 'thumbnail' ); ?>
            <?php } ?>
          </div>
          <p>
            <input type="button" class="button button-secondary showcase_tax_media_button" id="showcase_tax_media_button" name="showcase_tax_media_button" value="<?php _e( 'Add Image', 'showcase' ); ?>" />
            <input type="button" class="button button-secondary showcase_tax_media_remove" id="showcase_tax_media_remove" name="showcase_tax_media_remove" value="<?php _e( 'Remove Image', 'showcase' ); ?>" />
          </p>
        </td>
      </tr>
   <?php }

   /**
    * Update the form field value
    * @since 1.0.0
    */
   public function updated_category_image( $term_id, $tt_id ) {
     if( isset( $_POST['showcase-taxonomy-image-id'] ) && '' !== $_POST['showcase-taxonomy-image-id'] ){
       update_term_meta( $term_id, 'showcase-taxonomy-image-id', absint( $_POST['showcase-taxonomy-image-id'] ) );
     } else {
       update_term_meta( $term_id, 'showcase-taxonomy-image-id', '' );
     }
   }

   /**
    * Enqueue styles and scripts
    * @since 1.0.0
    */
   public function add_script() {
     if( ! isset( $_GET['taxonomy'] ) || $_GET['taxonomy'] != 'download_category' ) {
       return;
     } ?>
     <script> jQuery(document).ready( function($) {
       _wpMediaViewsL10n.insertIntoPost = '<?php _e( "Insert", "showcase" ); ?>';
       function ct_media_upload(button_class) {
         var _custom_media = true, _orig_send_attachment = wp.media.editor.send.attachment;
         $('body').on('click', button_class, function(e) {
           var button_id = '#'+$(this).attr('id');
           var send_attachment_bkp = wp.media.editor.send.attachment;
           var button = $(button_id);
           _custom_media = true;
           wp.media.editor.send.attachment = function(props, attachment){
             if( _custom_media ) {
               $('#showcase-taxonomy-image-id').val(attachment.id);
               $('#category-image-wrapper').html('<img class="custom_media_image" src="" style="margin:0;padding:0;max-height:100px;float:none;" />');
               $( '#category-image-wrapper .custom_media_image' ).attr( 'src',attachment.url ).css( 'display','block' );
             } else {
               return _orig_send_attachment.apply( button_id, [props, attachment] );
             }
           }
           wp.media.editor.open(button); return false;
         });
       }
       ct_media_upload('.showcase_tax_media_button.button');
       $('body').on('click','.showcase_tax_media_remove',function(){
         $('#showcase-taxonomy-image-id').val('');
         $('#category-image-wrapper').html('<img class="custom_media_image" src="" style="margin:0;padding:0;max-height:100px;float:none;" />');
       });
       // Thanks: https://stackoverflow.com/questions/15281995/wordpress-create-category-ajax-response
       $(document).ajaxComplete(function(event, xhr, settings) {
         var queryStringArr = settings.data.split('&');
         if( $.inArray('action=add-tag', queryStringArr) !== -1 ){
           var xml = xhr.responseXML;
           $response = $(xml).find('term_id').text();
           if($response!=""){
             // Clear the thumb image
             $('#category-image-wrapper').html('');
           }
          }
        });
      });
    </script>
   <?php }
  }
$Showcase_Taxonomy_Images = new Showcase_Taxonomy_Images();
$Showcase_Taxonomy_Images->init(); }

You can see that this follows exactly the same pattern as the first example to upload images for categories. However, note some of the differences. For example, in init() the action prefixes or suffixes must refer to the taxonomy slug, not to the category slug, e.g.:

add_action( 'download_category_add_form_fields', array( $this, 'add_category_image' ), 10, 2 );

See that the action is prefixed by download_category_. This is repeated for all the actions relating specifically to the taxonomy. You will need to update all instances of this term with your own custom taxonomy slug.
